Calculation methods. – conveyor belts. Content. 1. Terminology. 2. Unit goods conveying systems. 3. Take-up range for load-dependent take-up systems. 8. Conveyor and processing belts Calculation methods – conveyor belts Content Terminology 2 Unit goods conveying systems 3 Take-up range for. PDF | In this paper is done the explanation on tension fashion of the belt conveyor which is employed in Kosovo Energy Corporation – KEK, for coal.

In , Thomas Robins began a series of inventions which led to the development of a conveyor belt used for carrying coal, ores and other products.

In Richard Sutcliffe invented the first conveyor belts for use in coal mines which revolutionized the mining industry. Hyacynthe Marcel Bocchetti was the concept designer.

Incorporating a half-twist, it had the advantage over conventional belts of a longer life because it could expose all of its surface area to wear and tear. Structure[ edit ] The belt consists of one or more layers of material.

It is common for belts to have three layers: a top cover, a carcass and a bottom cover. The purpose of the carcass is to provide linear strength and shape.

The warp refers to longitudinal cords whose characteristics of resistance and elasticity define the running properties of the belt. The weft represents the whole set of transversal cables allowing to the belt specific resistance against cuts, tears and impacts and at the same time high flexibility.

The most common carcass materials are steel , polyester , nylon , cotton and aramid a class of synthetic fiber that includes Kevlar. The covers are usually various rubber or plastic compounds specified by use of the belt.
