The re-population of holes will lead to the change of their effective mass and thus their mobility, resulting in a change in SiC resistance or conductance. Firstly, a probe was attached to the SiC bridge.

Subsequently, the SiC resistors were transferred onto a glass substrate with aluminum contacts already deposited on it.

Finally, tungsten was deposited onto the transferred SiC resistors to enhance the electrical contact ESI. This assumption was confirmed as the resistance of the SiC elements before and after the FIB process showed no difference. Figure 4: The thermoresistive effect in p-type 3C-SiC transferred on glass substrate. Full size image The thermoresistive effect was then investigated by increasing the temperature of the transferred SiC elements using a high temperature oven.

It can be seen from Fig.

This decrease in SiC resistance is due to the thermally activated carrier concentration From the relationship between the change of SiC resistance and its temperature, the temperature of the SiC element under the Joule heating effect can be estimated. Joule heating in released SiC structures The Joule heating effect was then employed to locally raise the temperatures of the SiC resistors. The physical model of the Joule heating effect in our released SiC resistor is established based on the model of suspended beam heaters, which have been extensively investigated in gas sensors 44 , The heat losses in the SiC bridges are caused by thermal conduction through the released beam to the anchor parts, thermal convection through the surrounding air, and thermal radiation.

Toán rời rạc (1)

Figure 5 a Simulation of the Joule heating effect on released SiC resistor using Comsol Multiphysics; b The relationship between the resistance of p-type 3C-SiC resistor and the heating power at the steady state, using the current mode and voltage mode.

The decrease in SiC resistance at high applied power indicates that the Joule heating effect has significantly raised the temperature of SiC resistance; c Temperature at SiC resistor calibrated from Fig. The non-linearity between the applied power and temperature is considered due to thermal radiation in nano structures at high temperatures Full size image We conducted the Joule heating effect experiment on the released SiC resistors employing two different modes: constant current and constant voltage.

Both modes showed the same result that, when the heating power was increased, the resistance of SiC decreased. Figure 5 b presents the experimental results of the relationship between the supplied power and the SiC resistance at the steady state. The decrease in the resistance of SiC with increasing heating power obeys the thermoresistive effect presented in the previous section where increasing the temperature of the SiC element could increase its carrier concentration, thus enhance its electrical conductance.

Additionally, by correlating the results in Figs 5 b and 4 , it is possible to develop the relationship between the temperature of the SiC resistor when a certain power is applied, as shown in Fig.

This result is also in solid agreement with the simulation result. Due to the low heat loss caused by thermal conductance of the thin bridge, high temperatures mainly concentrated at the SiC resistor. Additionally, the temperature decreased significantly along the released bridge towards the fixed electrode pads. Therefore, the Joule heating effect can elevate the temperature of the SiC resistors and prevent the current leaking through the substrate. This result allowed us to characterize the piezoresistive effect in 3C-SiC on Si substrate in situ, which is presented as follows.

The gauge factor of p-type 3C-SiC was calculated to be approximately 28, which is the same as the result measured using the multimeter. However, under a high applied heating power e. Figure 6 shows that under the same mechanical load and heating power, the change of SiC resistance in constant voltage mode is larger than that of the constant current mode.

This phenomenon was considered to be due to the combination of piezoresistance and thermoresistance in the heated SiC element under strain, as illustrated in Fig.

Figure 6: Characterization of the piezoresistive effect at high temperature using the Joule heating effect. The relative resistance change at a small applied power b high applied power.

The red line shows the output of the constant current mode, while the blue line illustrates the output of the constant voltage mode. Full size image Figure 7 a The combination of thermoresistance and piezoresistance in the heated SiC resistors under strain; b The calculation method of the true gauge factor.

Full size image The combination phenomenon can be qualitatively explained as follows. Initially, under the Joule heating effect which raises the temperature of the SiC element T , the resistance of SiC decreases to R0 at steady state due to the thermoresistance.

Furthermore, this increase in the resistance will change the heating power supplied to the SiC element. The change of heating power in turn results in a change of resistance of the SiC piezoresistors following the thermoresistive effect. Based on the combination phenomenon and the observed gauge factor at constant current and constant voltage modes, we propose a method to extract the piezoresistive effect from the influence of the thermoresistive effect at high temperature.

It can be assumed from the diagram in Fig. Therefore, the true gauge factor of the piezoresistive effect at temperature T, should be within the gauge factors of GFI and GFV since the combination of thermoresistance and piezoresistance will enhance the gauge factor of SiC at the constant voltage mode; conversely the combination phenomenon reduces the gauge factor at the constant current mode.

Related titles

However, this relationship can be linearized within a smaller interval of powers by applying the Taylor series expansion to a monotonically decreasing function. Therefore, in the combination phenomenon, the heating power and resistance change can exhibit a linear relationship as the change of resistance at the steady state was relatively small below 0. A detailed explanation of the linear approximation of the relationship between the heating powers and resistances is presented in the ESI.

Additionally, using equation 7 , the gauge factors of p-type 3C-SiC at different temperatures were calculated and plotted in Fig. This result is understandable due to the fact that the p-type 3C-SiC was relatively highly doped, making its piezoresistive effect more stable at high temperatures.

The results also indicate that p-type 3C-SiC is a good candidate for applications operated at high temperatures where Si cannot be used. Figure 8: Calculated gauge factor of SiC at different heating temperatures. Full size image In conclusion, this work reports the piezoresistive effect in p-type 3C-SiC at high temperatures of up to K, characterized using an in situ measurement method.

With a gauge factor of above 25 at K, as well as a small deviation compared to the gauge factor at room temperature, highly doped p-type 3C-SiC is a promising poly type for mechanical sensing applications used in harsh environments. Thus, both the piezoresistive and thermoresistive effects will contribute to the modification in the electrical conductance of SiC under stress.

From the change in SiC resistance due to this combined effect, the gauge factor of p-type 3C-SiC at high temperatures can be obtained. The following sections present: i the bending method used to characterize the piezoresistive effect; ii the thermoresistive effect used to monitor the temperature of the heated SiC resistor; iii the Joule heating effect for locally increasing the temperature of SiC; and iv separation of the piezoresistive effect from the combination phenomenon.

Figure 2: The proposed in situ measurement. Full size image The piezoresistive effect of 3C-SiC at room temperature The piezoresistive effect of the released 3C-SiC was initially investigated at room temperature.

You might also like: ASTM E1290 PDF

The strain was induced into the SiC frame by employing the bending beam method. One end of the Si beam was fixed using a metal clamp, while the free end was deflected. Since the released SiC bridges were fixed to the Si substrate at their two ends, we expected that the strain would be induced into the SiC resistors following the bending of the Si cantilever 40 , Therefore, the strain applied to the fabricated SiC resistor can be approximated using equation 1.

Figure 3 a Simulation result of the strain applied to the SiC resistor when bending the Si cantilever inset: a comparison between the strain induced into the SiC resistor dart line and that of the top surface of the Si substrate solid line ; b The relationship between the relative resistance change of the p-type 3C-SiC resistor and the applied strain at room temperature. The applied current of the multimeter was set at nA, at which the Joule heating effect is considered to be negligible. At a small applying current of nA from the multimeter, the Joule heating effect in 3C-SiC resistor is considered to be negligible.

The gauge factor of p-type 3C-SiC has a positive value and is at least 15 times larger than that of metals. The piezoresistive effect in p-type 3C-SiC can be qualitatively explained due to the redistribution of holes in the top valance bands. Under a mechanical strain, these bands e.

The re-population of holes will lead to the change of their effective mass and thus their mobility, resulting in a change in SiC resistance or conductance. Firstly, a probe was attached to the SiC bridge.

Subsequently, the SiC resistors were transferred onto a glass substrate with aluminum contacts already deposited on it. Finally, tungsten was deposited onto the transferred SiC resistors to enhance the electrical contact ESI.

An-toan-lop-23.pdf - 1 AN TON LP 2 Nguyen Hong Son 2 Gii...

This assumption was confirmed as the resistance of the SiC elements before and after the FIB process showed no difference. Figure 4: The thermoresistive effect in p-type 3C-SiC transferred on glass substrate. Full size image The thermoresistive effect was then investigated by increasing the temperature of the transferred SiC elements using a high temperature oven. It can be seen from Fig. This decrease in SiC resistance is due to the thermally activated carrier concentration From the relationship between the change of SiC resistance and its temperature, the temperature of the SiC element under the Joule heating effect can be estimated.

Joule heating in released SiC structures The Joule heating effect was then employed to locally raise the temperatures of the SiC resistors. The physical model of the Joule heating effect in our released SiC resistor is established based on the model of suspended beam heaters, which have been extensively investigated in gas sensors 44 , The heat losses in the SiC bridges are caused by thermal conduction through the released beam to the anchor parts, thermal convection through the surrounding air, and thermal radiation.

Figure 5 a Simulation of the Joule heating effect on released SiC resistor using Comsol Multiphysics; b The relationship between the resistance of p-type 3C-SiC resistor and the heating power at the steady state, using the current mode and voltage mode.

The decrease in SiC resistance at high applied power indicates that the Joule heating effect has significantly raised the temperature of SiC resistance; c Temperature at SiC resistor calibrated from Fig.

The non-linearity between the applied power and temperature is considered due to thermal radiation in nano structures at high temperatures Full size image We conducted the Joule heating effect experiment on the released SiC resistors employing two different modes: constant current and constant voltage.

Both modes showed the same result that, when the heating power was increased, the resistance of SiC decreased. Figure 5 b presents the experimental results of the relationship between the supplied power and the SiC resistance at the steady state. The decrease in the resistance of SiC with increasing heating power obeys the thermoresistive effect presented in the previous section where increasing the temperature of the SiC element could increase its carrier concentration, thus enhance its electrical conductance.

Additionally, by correlating the results in Figs 5 b and 4 , it is possible to develop the relationship between the temperature of the SiC resistor when a certain power is applied, as shown in Fig.

This result is also in solid agreement with the simulation result. Due to the low heat loss caused by thermal conductance of the thin bridge, high temperatures mainly concentrated at the SiC resistor. Additionally, the temperature decreased significantly along the released bridge towards the fixed electrode pads. Therefore, the Joule heating effect can elevate the temperature of the SiC resistors and prevent the current leaking through the substrate.

This result allowed us to characterize the piezoresistive effect in 3C-SiC on Si substrate in situ, which is presented as follows. The gauge factor of p-type 3C-SiC was calculated to be approximately 28, which is the same as the result measured using the multimeter.

However, under a high applied heating power e.

Figure 6 shows that under the same mechanical load and heating power, the change of SiC resistance in constant voltage mode is larger than that of the constant current mode. This phenomenon was considered to be due to the combination of piezoresistance and thermoresistance in the heated SiC element under strain, as illustrated in Fig. Figure 6: Characterization of the piezoresistive effect at high temperature using the Joule heating effect.

The relative resistance change at a small applied power b high applied power. The red line shows the output of the constant current mode, while the blue line illustrates the output of the constant voltage mode. Full size image Figure 7 a The combination of thermoresistance and piezoresistance in the heated SiC resistors under strain; b The calculation method of the true gauge factor. Full size image The combination phenomenon can be qualitatively explained as follows.Hi ton on c bao nhiu ngi?

Hnh 3. Mt li gii bi ton ca bi ton vi /7 =1 2

Hi c hai thng ng c bao nhiu lt du? Hy cho bit c bao nhiu s t nhin ln hn 24 v nh hn 79? Since the released SiC bridges were fixed to the Si substrate at their two ends, we expected that the strain would be induced into the SiC resistors following the bending of the Si cantilever 40 , Lp n li c chia 2: thi bn sng v thi bi.
